FuelTech Junior Dragster EFI Kit

Liguori Drag Racing has put together a complete kit to install a FuelTech FT450 on to your Junior Dragster. This dedicated package is specifically designed to install electronic fuel injection onto your car as well as having the capabilities to control ignition timing, closed loop fuel tuning, and datalogging. You will need a windows style laptop.

Some things you will need when converting to this combination:

• You need a 6an return port back into your fuel cell.
• You need a 6an feed line from your fuel cell to the fuel pump.
• If running alcohol, you need to flush your fuel system with gasoline to keep your fuel pump and lines clean after each race.
• You will need a battery onboard. We can supply you with a battery and battery box or you can use your own. The FT450 CAN NOT exceed 20 Volts.
• This kit is an install it yourself kit. This means mounting all components, wiring and plumbing the fuel system. Liguori Drag Racing can assist with your install if you purchase this kit through us at no additional charge. ** If you do not want to install it yourself, we can do it for you if you bring the car to us in Northeast Ohio. We can also build a custom harness without the car and mail it to you. Please call us or email for more information. 330-219-9526 or David@LiguoriDragRacing.com
• This kit will come with a base map and basic wiring information also. Base map will be emailed to you.


FuelTech Junior Dragster EFI kit includes:

• FuelTech FT450
• Unterminated harness
• Aluminum blow shield mount with USB mount. Powder coated gloss black.
• FuelTech throttle body with throttle position sensor and idle adjustment screw.
• FuelTech FT Injector 80 lb/hr
• FuelTech O2 Nano
• FuelTech O2 Nano Harness
• O2 Sensor with weld on bung
• FuelTech EGT-4
• FuelTech EGT-4 Harness
• EGT Sensor and weld on bung
• FuelTech IGN1A Smart coil with connector
• Cylinder head temp sensor for spark plug
• 60-2 Crank trigger wheel for ARP adjustable flywheels
• Crank trigger sensor
• 12 Tooth jackshaft collar
• Jackshaft speed sensor
• Fuel Pump
• Fuel Regulator
• Fuel Filter
• Fuel pressure sensor
• 12V relay, fuel pump relay and coil relay

Optional upgrades available:

• You can upgrade from the regular O2 Nano to a NanoPro. Both provide you with O2 sensor data and allow the ecu to run in closed loop fuel tuning. The difference is that the NanoPro can display additional information such as engine temp and engine RPM, it can also be used as a switch panel to turn on various extras such as interior lights, exterior lights and a driver fan all directly from its touchscreen control. NanoPro can be installed in the driver's cockpit with limited information available to the driver while the FuelTech FT450 is mounted on the blow shield.

• You can upgrade to a dial board. This integrates with the FuelTech FT450 where you change the dial in on the touchscreen of the FT450. I currently do not have a junior dragster specific mount for the dial boards but I'm working on that solution.

• You can upgrade to a fitting and hose kit. What this means, it's a universal fuel fitting and hose kit with a few different 6an fitting and 6ft of 6an hose. Not all fittings on every car will be the same so you may have left over fittings or need additional fittings as this is just a generic kit.
