FT INJECTOR 230 LB/H
FT INJECTOR 230 LB/H
FuelTech USA
Regular price
$279.00 USD
Regular price
Sale price
$279.00 USD
Unit price
per
Couldn't load pickup availability
The FT Injector is compatible with any ECU available on the market and an 8A/2A Peak and Hold injector driver required.
FEATURES
- REAL flow, all injectors are tested, and calibrated to ensure linearity, repeatability and accuracy for all cylinders.
- It has internal components resistant to corrosion, guaranteed by the salinization test carried out on all raw material used
- Reduce the number of injectors, connections and hoses in your project;
- Compatible with any type of fuel (Gasoline, Ethanol, nitromethane, nitropropane, MTBE and ETBE)
- Tested and approved on +4,000 horsepower engines
- Compatible with any ECU on the market
- Use outputs from your ECU (by reducing the number of injectors)
- FuelTech warranty and support
- Project developed prioritizing the quality and durability of the injector.
TECHNICAL DESCRIPTION
- Low impedance: 1.5 Ohms
- It is necessary to use an 8A/2A Peak and Hold driver
- Voltage limit: up to 24V
DIMENSIONS:
- Injector: 86 x 32 mm
- Packing: 223 x 162 x 60 mm
- Shipping packaging dimensions: 225 x 250 x 65 mm
WEIGHT: 160g
PRODUCT CONTENT:
- 1 FT Injector
- 1 Manual
WARRANTY: 90 days
